spare parts
HL01108DProduct overview / Shower traysWaste gasket for HL520F
HL0520.0EProduct overview / Shower traysfunction lot cover / assembling tool for HL520-series
HL0520.1EProduct overview / Shower trayswaste valve for HL520-series
HL0520F.2EProduct overview / Shower traysTrap seal cartridge for HL520F-series
HL0520F.3EProduct overview / Shower traysHair strainer for HL520F
attachment
HL522.1Product overview / Shower trays / productsCover plate stainless steel d 112mm
HL522.11Product overview / Shower trays / productsCover plate gold plated d 112mm
HL522.2Product overview / Shower trays / productsCover plate solid brass d 112mm
HL522.3Product overview / Shower trays / productsCover plate white d 112mm
used with
HL0523N.1EProduct overview / Barriere-free showersSifon complete
HL523N-100x100Product overview / Barriere-free showers / Shower boardPrefabricated shower floor 100x100cm complete with ball joint outlet DN50/40 and sifon, in height adjustable frame 121x121cm and stainless steel grate 115x115mm
HL523N-120x120Product overview / Barriere-free showers / Shower boardPrefabricated shower floor 120x120cm complete with ball joint outlet DN50 and sifon, in height adjustable frame 121x121cm and stainless steel grate 115x115mm
HL523N-90x90Product overview / Barriere-free showers / Shower boardPrefabricated shower floor 90x90cm complete with ball joint outlet DN50/40 and sifon, in height adjustable frame 121x121cm and stainless steel grate 115x115mm
technical data
| material | PP/PE |
| dimension | DN40/50 |
| capacity |
| weight | 0,37 [kg] |
| EAN | 9003076037476 |
| installation height |
| grate frame |
| grate |
| load class |
| inlet |
| standards |
carton
| unit | 1 [pcs.] |
| weight | 0,519 [kg] |
| EAN/pack. | 9003076037476 |
| height/width/depth | 120/295/225 [mm] |
| volume | 0,007965000 [m3] |
single use pallet
| unit | 182 [pcs.] |
| weight | 104,5 [kg] |
| EAN/pack. |
| height/width/depth | 1950/800/1200 [mm] |
| volume | 1,872000000 [m3] |
