balcony and terrace drain DN40/50 horizontal with flange, frost-and drought-proof flap seal, cut-to-size plastic grate frame 10 - 70 mm / 123 x 123 mm, stainless steel grate 115 x 115 mm. Comes with lot cover.
material | PP, Edelstahl |
dimension | DN40/50 |
capacity | 0,50 l/sec |
weight | 0,425 [kg] |
EAN | 9003076016853 |
installation height | 57 mm |
grate frame | 12-70mm/123x123mm |
grate | Edelstahl 115x115mm |
load class | K - 300 kg |
inlet |
standards | EN1253 |
unit | 1 [pcs.] |
weight | 0,612 [kg] |
EAN/pack. | 9003076016853 |
height/width/depth | 155/225/295 [mm] |
volume | 0,010288125 [m3] |
unit | 143 [pcs.] |
weight | 98 [kg] |
EAN/pack. |
height/width/depth | 1900/800/1200 [mm] |
volume | 1,824000000 [m3] |
