floor drain DN50/75/110 vertical with flange, trap seal PRIMUS, cut-to-size plastic extension 34 - 75 mm, cast iron grate frame 150 x 150 mm and - grate 137 x 137 mm. Comes with lot cover.
material | PP,PE,Guss |
dimension | DN50/75/110 |
capacity | 0,5 l/s |
weight | 2,433 [kg] |
EAN | 9003076004690 |
installation height | 158 mm |
grate frame | 34-73 mm/150x150 mm Guss |
grate | Gusseisen 137x137 mm |
load class | L - 1,5 t |
inlet |
standards | EN 1253 |
unit | 1 [pcs.] |
weight | 2,622 [kg] |
EAN/pack. | 9003076004690 |
height/width/depth | 155/225/295 [mm] |
volume | 0,010288125 [m3] |
